SPEC&PRICE

GRADE & PRICE AT (Monotone)

1,760,000

AT (Two-Tone)

1,790,000

GRADE & PRICE


GRADE
AT

Overall length  (mm)

Front  bumper to  rear bumper

3,480

Front bumper to spare wheel cover

3,645

Overall width (mm)

1,645

Overall height  (mm)

1,720

Wheelbase   (mm)

2,250

Front tread  (mm)

1,395

Rear tread    (mm)

1,405

Minimum turning radius (m)

4.9

Minimum ground clearance (mm)

210

Seating capacity (person)

4

Fuel tank capacity (litres)

40

Luggage capacity (litre)

Max. volume (litre)

830

Rear seats folded (litre)

377

Rear seats raised (litre)

85

Engine

K15B 4 cylinders 16 valves

Piston displacement (cc)

1,462

Bore x stroke (mm)

74.0 x 85.0

Compression ratio

10

Maximum outout (PS/rpm)

102/ 6,000

Maximum torque (Nm/rpm)

130/ 4,000

Fuel distribution

Multipoint injection

Gear ratio

1st

2.875

2nd

1.568

3rd

1.000

4th

0.697

Reverse

2.300

Final gear ratio

4.300

Transfer gear ratio

High

1.320

Low

2.644

Steering

Recirculating ball

Brakes

Front

Solid disc

Rear

Drum leading and trailing

Suspension

Front

3-link rigid axie with coil spring

Rear

3-link rigid axie with coil spring

Wheel

195/80 R15

Kerb weight (kg)

1,095-1,110

Gross vehicle weight (kg)

1,435


Overall length

Front  bumper to  rear bumper

3,480

3,480

Front bumper to spare wheel cover

3,645

3,645

Overall width (mm)

1,645

1,645

Overall height  (mm)

1,720

1,720

Wheelbase   (mm)

2,250

2,250

Front tread  (mm)

1,395

1,395

Rear tread    (mm)

1,405

1,405

Minimum turning radius (m)

4.9

4.9

Minimum ground clearance (mm)

210

210

Seating capacity (person)

4

4

Fuel tank capacity (litre)

40

40

Luggage capacity (litre)

Max. volume (litre)

830

830

Rear seats folded (litre)

377

377

Rear seats raised (litre)

85

85

Engine

K15B 4 cylinders 16 valves

K15B 4 cylinders 16 valves

Piston displacement (cc)

1,462

1,462

Bore x stroke (mm)

74.0 x 85.0

74.0 x 85.0

Compression ratio

10

10

Maximum outout (PS/rpm)

102/ 6,000

102/ 6,000

Maximum torque (Nm/rpm)

130/ 4,000

130/ 4,000

Fuel distribution

Multipoint injection

Multipoint injection

Gear ratio

1st

2.875

2.875

2nd

1.568

1.568

3rd

1.000

1.000

4th

0.697

0.697

Reverse

2.300

2.300

Final gear ratio

4.300

4.300

Transfer gear ratio

High

1.320

1.320

Low

2.644

2.644

Steering

Recirculating ball

Recirculating ball

Brakes

Front

Solid disc

Solid disc

Rear

Drum leading and trailing

Drum leading and trailing

ระบบกันสะเทือน

Front

3-link rigid axie with coil spring

3-link rigid axie with coil spring

Rear

3-link rigid axie with coil spring

3-link rigid axie with coil spring

Wheel

195/80 R15

195/80 R15

Kerb weight (kg)

1,080-1,095

1,080-1,095

Gross vehicle weight (kg)

1,435

1,435
